123
T89C51CC01
Rev. D – 17-Dec-01
17.9 Registers Table 87. ADCF Register
ADCF (S:F6h)
ADC Configuration
Reset Value=0000 0000b
Table 88. ADCON Register
ADCON (S:F3h)
ADC Control Register
Reset Value=X000 0000b
7 6 5 4 3 2 1 0
CH 7 CH 6 CH 5 CH 4 CH 3 CH 2 CH 1 CH 0
Bit
Number
Bit
Mnemonic Description
7-0 CH 0:7
Channel Configuration
Set to use P1.x as ADC input.
Clear to use P1.x as standart I/O port.
7 6 5 4 3 2 1 0
- PSIDLE ADEN ADEOC ADSST SCH2 SCH1 SCH0
Bit
Number
Bit
Mnemonic Description
7 -
6 PSIDLE
Pseudo Idle mode (best precision)
Set to put in idle mode during conversion
Clear to convert without idle mode.
5 ADEN
Enable/Standby Mode
Set to enable ADC
Clear for Standby mode (power dissipation 1 uW).
4 ADEOC
End Of Conversion
Set by hardware when ADC result is ready to be read. This flag can generate an
interrupt.
Must be cleared by software.
3 ADSST
Start and Status
Set to start an A/D conversion.
Cleared by hardware after completion of the conversion
2-0 SCH2:0
Selection of channel to convert
see Table 86
