105
T89C51CC01
Rev. D – 17-Dec-01
Table 72. CANTCON Register
CANTCON (S:A1h)
CAN Timer ClockControl
Reset Value: 00h
Table 73. CANTIMH Register
CANTIMH (S:ADh Read Only)
CAN Timer High
Reset Value: 0000 0000b
Table 74. CANTIML Register
CANTIML (S:ACh Read Only)
CAN Timer Low
Reset Value: 0000 0000b
7 6 5 4 3 2 1 0
TPRESC 7 TPRESC 6 TPRESC 5 TPRESC 4 TPRESC 3 TPRESC 2 TPRESC 1 TPRESC 0
Bit
Number
Bit
Mnemonic Description
7-0
TPRESC7:
0
Timer Prescaler of CAN Timer
This register is a prescaler for the main timer upper counter
range = 0 to 255.
See Figure 38.
7 6 5 4 3 2 1 0
CANGTIM
15
CANGTIM
14
CANGTIM
13
CANGTIM
12
CANGTIM
11
CANGTIM
10
CANGTIM
9
CANGTIM
8
Bit
Number
Bit
Mnemonic Description
7-0
CANGTIM
15:8
High byte of Message Timer
See Figure 38.
7 6 5 4 3 2 1 0
CANGTIM
7
CANGTIM
6
CANGTIM
5
CANGTIM
4
CANGTIM
3
CANGTIM
2
CANGTIM
1
CANGTIM
0
Bit
Number
Bit
Mnemonic Description
7-0
CANGTIM
7:0
Low byte of Message Timer
See Figure 38.
