Gas sampling and gas conditioning technology 2-1.1.5-ME

Push the filter housing cover with preliminary filter or sample tube into the filter space  in the
probe head.

Swing clamp B to the right and with handle C bring eye bolt D in position E, so that the clamp
engages in eye bolt D and threaded bolt H; if necessary, push in or pull out the filter housing cover
slightly with the clamping screw A;

Turn handle C into position F and tighten handle A hand-tight by turning clockwise.
12.3 CONNECTION OF SAMPLE LINE
Provided on the probe side for connection of the sample line is a ¼“ NPTi thread. This thread can be
used for screwing in appropriate connecting unions for lines with the sizes Ø6mm (standard), 8mm or
10mm.
The sample line is connected as follows:

Loosen the toggle-type fasteners on the insulating cover and hood and remove.

Screw the appropriate threaded union into the probe head with sealing tape.

Insert the line through the respective opening in the probe base plate and silicone holder.

Connect the line to the union. For Swagelok
®
fittings:
- Fully insert the liner with support sleeve into the union.
- Tighten the union nut finger-tight.
-
Prior to tightening, mark the union nut in the 6 o’clock position.
- Grip the body with a spanner and tighten the union nut with 11/4 turns; after a full turn, the mark
must be turned further to the 9 o’clock position.
N O T E !
When connecting hose assemblies to stainless steel unions, a supporting
sleeve must always be used.
The connection must be checked for leaks.

Refit the special hood and close with clamps.
