Gas sampling and gas conditioning technology 2-1.1.5-ME
7.1 OPTIONS
The following list shows the options available. The diversity of options and modular design of M&C
gas sample probes ensure optimum probe selection to suit the particular process and ambient
conditions.
Description Article No.
Basic typeSP2500H, heated to 0-180°C, with weatherproof cover,
Material stainless steel 1.4571 20 S 3510
Basic type SP2500-H/C/I/BB, heated to 180°C, with weatherproof cover,
Material stainless steel 1.4571 20 S 3520
Basic type SP2500-H/C/I/BB/F, heated to 0-180°C, with weatherproof cover,
Material stainless steel 1.4571 20 S 3500
.
Power supply 115V/60Hz/115V 20 S 9030
Type with second sampled gas outlet 1/4" NPTi*/2x* 20 S 9015
Type with backflushing/calibration gas supply valve (C*), opening pressure 0.7 bar,
tube 8 mm* 20 S 9435
Type with glass filter element 0.1GF150, filter fineness 0.1 µm,
seal PTFE/GF150 20 S 9020
Type with special filter housing cover with spun glass cartridge
Including spun glass filling, seal FPM, Novapress/FW 20 S 9047
Type with PT100 sensor instead of capillary controller,
without thermostat/PT100 20 S 9025
Type with thermocouple Fe-CuNi (type J) instead of capillary controller,
without thermostat/Fe-CuNi 20 S 9027
Type with thermocouple Ni-CrNi (type K) instead of capillary controller,
without thermostat/Ni-CrNi 20 S 9028
Type with second PT100 sensor/2-PT100 20 S 9026
Type with special intermediate flange adapter DN..PN6 or ANSI..150 lbs/DN 20 S 9004
Support tube adapter type SP2500H/SA500 for supporting the installation of long sample
tubes and preliminary filters with extension tube, including flange gasket, material 1.4571 20 S 9433
Type with gas pre-heater GVW1, material stainless steel 2-1.2.5/GVW1 20 S 9058
Connection of gas pre- heater to connection “BB“ and gas inlet/GVW 20 S 9062
Type with steam heating without regulating and valves
Instead of capillary controller/D 20 S 9033
* only SP2500-H
