14
Gas sampling and gas conditioning technology 10-1.1.1-ME
W A R N I N G ! Also after switching off the mains voltage touching the catalyst
cartridge can lead to serious burns. Wear protective gloves.
15.1 THE EXTERNAL PARTICLE-CONDENSATE-FILTER
W A R N I N G !
The air conditioning is operated with max. 145 psi inlet pressure.
Before maintaining the filter the device has to be disconnected
from the pressure air.
W A R N I N G !
At a condensate level of 10mm below the Filterelement (see
marking) the condensate has to be drained because otherwise the
air conditioning will be damaged.
15.1.1 DRAIN OF THE CONDENSATE

Disconnect the device from the pressure air supply.

Open drain screw anti clockwise seen from below.

Condensate is draining off.
For the condensate connection a hose connector for tube 4/6mm is exsisting.
15.1.2 CHANGE OF THE FILTER CARTRIDGE
Changing the filter cartridge may be necessary in case of decreasing air flow.
For a change of the filter cartridge the following steps must be carried out:

Disconnect pressure air from the filter

Wait until the pressure in the device has decreased to ambient pressure (control at the
manometer)

Push unlock slider in direction of the arrow

Turn filter housing anti clockwise (seen from below) and remove it downwards

Turn filter cartridge anti clockwise

Touch new filter cartridge only at the lower end

Mount the parts in reverse order
