XTnano – Version 10.03 – Configuration Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.D
3
Setup page and section
name
Content
Page 5 Not available for XTnano.
Page 6
See section 2.6 ‘HCTX
Gigabit Connection Settings
(Page 6)’, on page 21 and
2.7 ‘LAN Connection Settings
(Page 6)’, on page 22
It includes detailed settings on the HCTX gigabit
connection and the MTPC board connection.
Page 7/8/9 Not available for XTnano.
Page 10
See section 2.8 ‘Multiviewer
Settings (Page 10)’, on page
24
It includes the settings for the connection of an
external multiviewer.
2.1.2 H
OW TO
A
CCESS THE
S
ETUP
C
ONFIGURATION
The Setup Configuration module is available by pressing simultaneously
SHIFT + F2 on the keyboard with CAPS LOCK disabled. The Setup Configuration
is not accessible if CAPS LOCK is ON.
2.1.3 H
OW TO
M
OVE
I
NSIDE THE
S
ETUP
C
ONFIGURATION
• Use TAB or SHIFT + TAB to move from one parameter to the next or previous
one, and the LEFT or RIGHT ARROW keys to change the value of a parameter.
• Use PAGE UP and PAGE DOWN to access the other configuration screens.
