73

Remote Interface Reference

Status System Commands

*ESE 60;

*ESE?

The

*ESE?

query returns a decimal sum which corresponds to the binary-

weighted sum of the bits enabled by the last

*ESE

command.

*OPC

Sets the “Operation Complete” bit (bit 0) of the Standard Event register
when executed. See page 69 for a complete discussion.

*OPC?

Returns “1” to the requesting interface when executed. See page 69 for
more information.

{CH1|CH2|CH3|CH4}:STATus:ALARm:CONDition?

Returns the contents of an Alarm Condition register as a binary-weighted
sum.

{CH1|CH2|CH3|CH4}:STATus:ALARm:EVENt?

Returns the contents of an Alarm Event register as a binary-weighted
sum.

{CH1|CH2|CH3|CH4}:STATus:ALARm:ENABle <

enable_value

>

Enables bits in an Alarm Event register to be reported in the “Alarm
Event” bit (bit 2) of the Status Byte register. To enable bits, you must
write a decimal

<

enable_value

>

which corresponds to the binary-weighted

sum of the bits you wish to enable. Refer to Table 5-3 on page 66 for more
information. For example, to enable all alarm events for Channel 1 to be
reported in bit 0 of the Status Byte register, send:

CH1:STATus:ALARm:ENABle 255;

{CH1|CH2|CH3|CH4}:STATus:ALARm:ENABle?

Returns a decimal sum which corresponds to the binary-weighted sum of
the bits enabled by the last

{CH1|CH2|CH3|CH4}:STATus:ALARm:ENABle

<

enable_value

>

command.

STATus:MEAS:CONDition?

Returns the contents of an Measurement Condition register as a binary-
weighted sum.

STATus:MEAS:EVENt?

Returns the contents of an Measurement Event register as a binary-
weighted sum.
