Operation

Menu Reference

opened, and will be re-initiated on contact closure. This option is
useful for applications where critical operations may require
minimum external disturbances.

If the

None

option is selected, the contact input will be ignored and

the fill cycle will initiate and terminate normally. The default
selection is

None

.

4.3.8

FILL Menu in Auto-Changeover Mode

In the auto-changeover controller mode, the FILL menu provides four
menu screens for Channel 1. Each of the menu screens is accessible by
repeatedly pressing the

MENU

key, and include interfaces for setting the

AC output states, selecting the empty detection method, and setting
timeouts. The auto-changeover mode manages auto-fill cycles

1

from two

storage vessels.

4.3.8.1

AC Output 1

Controls the state of AC Output 1. Press the

OPTION

key to cycle

between the three selections. The 1:FILL LED indicates the
energized or de-energized state. The

Auto

selection allows the

Model 286 to manage the auto-fill cycles between the two storage
vessels.

4.3.8.2

AC Output 2

Controls the state of AC Output 2. Press the

OPTION

key to cycle

between the three selections. The 2:FILL LED indicates the
energized or de-energized state. The

Auto

selection allows the

Model 286 to manage the auto-fill cycles between the two storage
vessels.

1. An “auto-fill cycle” in the auto-changeover mode is initiated by a liquid level less

than the B setpoint of Channel 1, and is terminated once the liquid level reaches or
exceeds the A setpoint of Channel 1.

AC Output 1:

On Off

$Auto

AC Output 2:

On Off

$Auto
