34

Calibration

Calibration Menu Reference

Toggle the units key before beginning entry (or after

ESC

from an

entry in progress) to toggle the units.

The active length must be entered. The active length corresponds to
the physical distance measured between the desired MIN and MAX
points of the sensor.

Note

The active length value should be set to the length which is to be
physically calibrated in the Open or Closed Dewar Calibration
method, or the L

active

value used for the Approximate Calibration

method calculations as documented in paragraph 3.2.3 on page 26.

Once a value has been entered using the

ENTER

key, press the

MENU

key to proceed. If a value has not been entered, the Model 286

will not allow the user to proceed to the next calibration step.

Note

The active length setting can be re-adjusted after MIN/MAX entry
without affecting the MIN/MAX calibration of the instrument.

3.3.5.3 MIN/MAX entry

Before entering the MIN or MAX points, the operator should ensure
that the sensor is properly connected to the Model 286, and that the
cabling configuration is as close as possible to the configuration
used during operation (with the exception of the extension cable).
The sensor should also be cooled to near the operating temperature
to mitigate the effects of any mechanical distortions that may arise
between room temperature and cryogenic temperature.

Note

The MIN and MAX entry can be performed in any order, and can be
performed multiple times. The only requirement is that at least one
MIN and one MAX calibration must be performed to permit the
instrument to make a measurement.

Note

If the instrument beeps twice, then either the just entered MIN point
is greater than a previously entered MAX point, or vice-versa. In
that event, the Model 286 invalidates the previously entered point

A: MIN - Press 7

MAX - Press 8
