ES-3124 User’s Guide
Chapter 4 The Web Configurator 59
Figure 18 Example Xmodem Upload
7 After a configuration file upload, type atgo to restart the switch.
Figure 19 Reload the Configuration file: Via Console Port
The switch is now reinitialized with a default configuration file including the default password
of “1234”.
4.7.2 Reset to the Factory Defaults
To reset the switch back to the factory defaults, do the following:
1 Connect to the console port using a computer with terminal emulation software. See the
chapter on hardware connections for details.
2 Disconnect and reconnect the switch's power to begin a session. When you reconnect the
switch's power, you will see the initial screen.
3 When you see the message " Press any key to enter Debug Mode within 3
seconds " press any key to enter debug mode.
Bootbase Version: V0.6 | 03/06/2006 09:21:13
RAM:Size = 32 Mbytes
DRAM POST: Testing: 32768K OK
DRAM Test SUCCESS !
FLASH: Intel 32M
ZyNOS Version: 3.70(AID.0)b0 | 4/28/2006 17:27:36
Press any key to enter debug mode within 3 seconds.
.................................
Enter Debug Mode
ES-3124> atlc
Starting XMODEM upload (CRC mode)....
CCCCCCCCCCCCCCCC
Total 262144 bytes received.
Erasing..
................................................................
OK
ES-3124> atgo
Type the configuration file's
location, or click Browse to
search for it.
Choose the 1K Xmodem
protocol.
Then click Send.
