ES-3124 User’s Guide
Chapter 38 IEEE 802.1Q Tagged VLAN Commands 297
C
H A P T E R
38
IEEE 802.1Q Tagged VLAN
Commands
This chapter describes the IEEE 802.1Q Tagged VLAN and associated commands.
38.1 Configuring Tagged VLAN
The following procedure shows you how to configure tagged VLAN.
1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the
switch.
• Use the vlan command to configure or create a VLAN on the switch. The
switch automatically enters the config-vlan mode.Use the inactive command to
deactivate the VLAN(s).
• Use the interface port-channel command to enter the config-
interface mode to set the VLAN settings on a port, then use the pvid
command to set the VLAN ID you created for the port-list to that specific port in the
PVID table.
• Use the exit command when you are finished configuring the VLAN.
2 Configure your management VLAN.
• Use the vlan command to create a VLAN (VID 3 in this example) for
managing the switch, and the switch will activate the new management VLAN.
• Use the inactive command to disable the new management VLAN.
ras (config)# vlan 2000
ras (config-vlan)# name up1
ras (config-vlan)# fixed 10-12
ras (config-vlan)# no untagged 10-12
ras (config-vlan)# exit
ras (config)# interface port-channel 10-12
ras (config-interface)# pvid 2000
ras (config-interface)# exit
ras (config)# vlan 3
ras (config-vlan)# inactive
