ES-3124 User’s Guide
114 Chapter 11 Spanning Tree Protocol
11.5 Configure Multiple Rapid Spanning Tree Protocol
To configure MRSTP, select MRSTP in the Advanced Application, Spanning Tree
Protocol screen. See
Section 11.1 on page 107 for more information on MRSTP.
Max Age (second) This is the maximum time (in seconds) a switch can wait without receiving a
configuration message before attempting to reconfigure.
Forwarding Delay
(second)
This is the time (in seconds) the root switch will wait before changing states (that
is, listening to learning to forwarding).
Cost to Bridge This is the path cost from the root port on this switch to the root switch.
Port ID This is the priority and number of the port on the switch through which this switch
must communicate with the root of the Spanning Tree.
Topology Changed
Times
This is the number of times the spanning tree has been reconfigured.
Time Since Last
Change
This is the time since the spanning tree was last reconfigured.
Table 26 Rapid Spanning Tree Protocol: Status (continued)
LABEL DESCRIPTION
