ES-3124 User’s Guide
178 Chapter 22 Multicast
The following table describes the related labels in this screen.
Table 55 MVR
LABEL DESCRIPTION
Active Select this check box to enable MVR to allow one single multicast VLAN to be
shared among different subscriber VLANs on the network.
Name Enter a descriptive name (up to 32 printable ASCII characters) for identification
purposes.
Multicast VLAN
ID
Enter the VLAN ID (1 to 4094) of the multicast VLAN.
802.1p Priority Select a priority level (0-7) with which the switch replaces the priority in outgoing
IGMP control packets (belonging to this multicast VLAN).
Mode Specify the MVR mode on the switch. Choices are Dynamic and Compatible.
Select Dynamic to send IGMP reports to all MVR source ports in the multicast
VLAN.
Select Compatible to set the switch not to send IGMP reports.
Port This field displays the port number on the switch.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this
row first to set the common settings and then make adjustments on a port-by-port
basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Source Port Select this option to set this port as the MVR source port that sends and receives
multicast traffic. All source ports must belong to a single multicast VLAN.
Receiver Port Select this option to set this port as a receiver port that only receives multicast
traffic.
None Select this option to set the port not to participate in MVR. No MVR multicast traffic
is sent or received on this port.
Tagging Select this checkbox if you want the port to tag the VLAN ID in all outgoing frames
transmitted.
Add Click Add to save your changes to the switch’s run-time memory. The switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are
done configuring.
Cancel Click Cancel to reset the fields.
VLAN This field displays the multicast VLAN ID.
Active This field displays whether the multicast group is enabled or not.
Name This field displays the descriptive name for this setting.
Mode This field displays the MVR mode.
Source Port This field displays the source port number(s).
Receiver Port This field displays the receiver port number(s).
802.1p This field displays the priority level.
Delete To delete a multicast VLAN(s), select the rule(s) that you want to remove in the
Delete column, then click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
