background image

Omni 56K II and Omni 56K Plus II User’s Guide

5-14

Command

Sets

COMMAND DESCRIPTION

VALUE

Only check 1D phase C data.

n=1

Check both 1D and 2D phase C data.

n=2

+FCR=n

"Capability to receive" parameter.

DCE will not receive message data or poll a remote device.

n=0

DCE receives message data or polls a remote device.

n=1

+FDCC=vr,br,wd,
ln,df,ec,bf,st

Sets the DCE capabilities parameters.

Sets Vertical resolution to Normal (98 lpi).

vr=0

Sets Vertical resolution to Fine (196 lpi).

vr=1

Bit rate: 2400 bit/s; V.27ter.

br=0

Bit rate: 4800 bit/s; V.27ter.

br=1

Bit rate: 7200 bit/s; V.29 or V.17.

br=2

Bit rate: 9600 bit/s; V.29 or V.17.

br=3

Bit rate: 12000 bit/s; V.17.

br=4

Bit rate: 14400 bit/s; V.17.

br=5

Page width: 1728 pixels in 215mm.

wd=0

Page width: 2048 pixels in 255mm.

wd=1

Page width: 2432 pixels in 303mm.

wd=2

Page length: A4; 297mm.

ln=0

Page length: B4; 364mm.

ln=1

Page length: unlimited length.

ln=2

Data compression format: 1-D; modified Huffman.

df=0

Data

compression format: 2-D; modified Read.

df=1

Disables

Error

correction.

ec=0

Disables binary file transfer.

bf=0

Minimum scan time/line: 0 ms.

st=0

Minimum scan time/line: 5 ms.

st=1
