Page 43
Omni 56K II and Omni 56K Plus II User’s Guide
Result Codes
4-1
Chapter 4
Result Codes
This chapter details the command responses for the Omni 56K II and Omni 56K Plus II modems.
4.1 Result
Codes
The result code is the command response or the Connect message to the DTE. The format of the result code
is dependent on the Xn and Vn commands. The lists are as follows:
Table 4-1 Result Codes
RESULT CODE FOR
ATV0 ATV1
X0 X1 X2 X3 X4 X5 X6 X7
0 OK
●
●
●
●
●
●
●
●
1 CONNECT
●
●
●
●
●
╬
╬
╬
2 RING
●
●
●
●
●
●
●
●
3 NO
CARRIER ●
●
●
●
●
●
●
●
4 ERROR
●
●
●
●
●
●
●
●
5 CONNECT
1200
●
●
●
●
╬
╬
╬
6 NO
DIAL
TONE
●
●
●
●
●
7 BUSY
●
●
●
●
●
8 NO
ANSWER
●
●
●
●
●
9 RINGING
●
●
●
●
●
10 CONNECT
2400
●
●
●
●
╬
╬
╬
11 CONNECT
4800
●
●
●
●
╬
╬
╬
12 CONNECT
9600
●
●
●
●
╬
╬
╬
14 CONNECT
19200
●
●
●
●
╬
╬
╬
15 CONNECT
7200
●
●
●
●
╬
╬
╬
