Omni 56K II and Omni 56K Plus II User’s Guide
Installation
2-3
The rear panel for the Omni 56K Plus II is identical to the rear panel of the Omni 56K Plus II, except that the
Omni 56K II does not have the USB port.
2.2 Connecting Your Omni 56K II (RS-232 Port)
Step 1. Connect your modem to your analog phone or fax.
Step 2. Use the phone cord included to connect to the phone jack on the wall.
Step 3. Plug one end of your RS-232 cable to your modem and the other end to your computer's serial
port.
Step 4. Use the included power adaptor to connect your modem to the power outlet. Turn on the
modem
Step 5. Turn on your computer and insert the included CD.
2.2.1
Driver Installation
Windows automatically starts an installation wizard when it detects new hardware. Use the wizard to select
the driver on your included CD. Browse to D:\Drivers\Omni56KII (where D: is your CD-ROM drive), and
click Next or OK.
