Text mode
Original mode

Note To use the factory defaults, click the Restore
Defaults button.

Changing telephone line dialing options

1. At your PC, double-click the WorkCentre icon.
2. In the WorkCentre 450c Status window, click Settings.
3. Click the Phone Line tab.
4. Change the defaults for any of these options:

Redials

Specifies the number of times, from 0 to 9, you want
the WorkCentre to redial a fax number after a failed
fax transmission.

Redial interval (min)

Specifies the interval, from 1 to 255 minutes,
between redials.

Pause length (secs)

Defines the interval, from 1 to 9 seconds, assigned
to the

PAUSE

key on the control panel. When you

press the

PAUSE

key in a dialing sequence, a

comma (,) displays on the LCD and the specified
time interval is inserted between the numbers.
