193

No Phonebook
entries to report.

You tried to print a
Phonebook, but there aren’t
any speed dial entries.

No action.

No yellow ink.
Load cartridge.

Either the yellow ink
cartridge is missing or an
ink cartridge made for
another machine is
installed in the WorkCentre.

Insert a Xerox color ink
cartridge.

No yellow ink. Press

CARTRIDGE

key.

The ink supply in the yellow
ink cartridge is out.

Insert a Xerox color ink
cartridge.

Open cover or press

EXIT

to clear scanner.

The document either
remained in the document
tray or was partially fed into
the scanner.

Press

EXIT/CLEAR

to clear the

document, or open the
scanner cover and remove
the document.

Out of paper.
Please add paper.

The WorkCentre is out of
paper.

Load up to 150 sheets of
paper in the paper tray.

Paper misfeed or
jam. Press

FEED

to

clear.

The paper did not load
properly into the printer.

Press the

FEED

key to clear

the misfed or jammed
paper.

Password
already in use.

You entered a password
used elsewhere on the
WorkCentre. For example,
you may have entered your
security password as the
password for a mailbox.

Enter a unique four-digit
password.

Password must
have 4 digits.

You did not enter a four-
digit password.

Check the password; be
sure to enter all four digits.

PC error. Reload
pages.

While using a PC
application to scan a
document, an error
occurred.

Reload the document in the
document tray and try
scanning again.

Message

Meaning

Action
