Chapter 7 Wireless LAN
User’s Guide
98
7.7 WPS Station
Use this screen when you want to add a wireless station using WPS. To open this
screen, click Network > Wireless LAN > WPS Station tab.
Note: Note: After you click Push Button on this screen, you have to press a similar
button in the wireless station utility within 2 minutes. To add the second wireless
station, you have to press these buttons on both device and the wireless station
again after the first 2 minutes.
Figure 51 WPS Station
The following table describes the labels in this screen.
Apply
Click Apply to save your changes back to the NBG4115.
Refresh
Click Refresh to get this screen information afresh.
Table 33 WPS
LABEL
DESCRIPTION
Table 34 WPS Station
LABEL
DESCRIPTION
Push Button
Use this button when you use the PBC (Push Button Configuration)
method to configure wireless stations’s wireless settings. See
.
Click this to start WPS-aware wireless station scanning and the wireless
security information synchronization.
Or input
station’s PIN
number
Use this button when you use the PIN Configuration method to
configure wireless station’s wireless settings. See
.
Type the same PIN number generated in the wireless station’s utility.
Then click Start to associate to each other and perform the wireless
security information synchronization.
