User’s Guide
211
A
P P E N D I X
A
Product Specifications
The following tables summarize the NBG4115’s hardware and firmware features.
Table 68 Hardware Features
Dimensions 140 mm (W) x 110 mm (D) x 30 mm (H)
Weight 190 g (without a 3G card installed)
SDRAM 32 MB
Flash Memory 4 MB
Power Specification Input: 120~240 AC, 50~60 Hz
Output: 12 V DC 1.25A
Ethernet ports Auto-negotiating: 10 Mbps, 100 Mbps in either half-duplex or full-
duplex mode.
Auto-crossover: Use either crossover or straight-through Ethernet
cables.
4-5 Port Switch A combination of switch and router makes your NBG4115 a cost-
effective and viable network solution. You can add up to four
computers to the NBG4115 without the cost of a hub when
connecting to the Internet through the WAN port. You can add up
to five computers to the NBG4115 when you connect to the
Internet in AP mode. Add more than four computers to your LAN
by using a hub.
LEDs PWR, LAN1-2, 3G, Internet, WAN, WLAN/WPS
Reset Button The reset button is built into the rear panel. Use this button to
restore the NBG4115 to its factory default settings. Press for 1
second to restart the device. Press for 5 seconds to restore to
factory default settings.
WPS button Press the WPS on two WPS enabled devices within 120 seconds
for a security-enabled wireless connection.
Antenna The NBG4115 is equipped with a 2dBi (2.4GHz) detachable
antenna to provide clear radio transmission and reception on the
wireless network.
USB Port The NBG4115 has one built-in USB 2.0 type A for 3G connectivity.
When a 3G card is plugged in and operational this port functions
as a WAN port.
Operation
Environment Temperature: 0º C ~ 40º C / 32ºF ~ 104ºF
Humidity: 20% ~ 90%
Storage Environment Temperature: -30º C ~ 70º C / -22ºF ~ 158ºF
Humidity: 20% ~ 95%
