The following table describes the LEDs and the WPS button.
Table 1 Front Panel LEDs and WPS Button
LED
COLOR
STATUS
DESCRIPTION
POWER
Green
On
The NBG4115 is receiving power and functioning
properly.
Off
The NBG4115 is not receiving power.
WLAN
Green
On
The NBG4115 is ready, but is not sending/
receiving data through the wireless LAN.
Blinking
The NBG4115 is sending/receiving data through
the wireless LAN.
The NBG4115 is negotiating a WPS connection
with a wireless client.
Off
The wireless LAN is not ready or has failed.
WAN
Green
On
The NBG4115 has a successful 10/100MB WAN
connection.
Blinking
The NBG4115 is sending/receiving data through
the WAN.
Off
The WAN connection is not ready, or has failed.
LAN 1-2
Green
On
The NBG4115 has a successful 10/100MB
Ethernet connection.
Blinking
The NBG4115 is sending/receiving data through
the LAN.
Off
The LAN is not connected.
3G
Green
On
The NBG4115 has a 3G card installed and is
communicating with routers.
Blinking
The NBG4115 is transmitting and/or receiving
data from routers through an installed 3G card.
Off
There is no 3G card installed.
Internet
Green
On
The NBG4115 has received an IP address
through either the WAN or WLAN interface and
can connect to the Internet.
Off
The NBG4115 has not received an IP address
through either the WAN or WLAN interface and
as such cannot connect to the Internet.
WPS Button
Press this button for 1 second to set up a wireless connection via WiFi
Protected Setup with another WPS-enabled client. You must press the
WPS button on the client side within 120 seconds for a successful
connection.
