Chapter 3 The Web Configurator
User’s Guide
34
3.5.2 Summary: DHCP Table
DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows
individual clients to obtain TCP/IP configuration at start-up from a server. You can
configure the NBG4115’s LAN as a DHCP server or disable it. When configured as a
server, the NBG4115 provides the TCP/IP configuration for the clients. If DHCP
service is disabled, you must have another DHCP server on that network, or else
the computer must be manually configured.
Click the DHCP Table (Details...) hyperlink in the Status screen. Read-only
information here relates to your DHCP status. The DHCP table shows current
Bandwidth
Management
General Use this screen to use pre-configured bandwidth
management profiles for how your NBG4115
manages incoming and outgoing data.
Advanced Use this screen to create your own bandwidth
management profile for how your NBG4115 manages
incoming and outgoing data.
Remote
MGMT
WWW Use this screen to configure through which
interface(s) and from which IP address(es) users can
use HTTP to manage the NBG4115.
UPnP General Use this screen to enable UPnP on the NBG4115.
Maintenance
System General Use this screen to view and change administrative
settings such as system and domain names,
password and inactivity timer.
Time Setting Use this screen to change your NBG4115’s time and
date.
Logs View Log Use this screen to view the logs for the categories
that you selected.
Tools Firmware Use this screen to upload firmware to your NBG4115.
Configuration Use this screen to backup and restore the
configuration or reset the factory defaults to your
NBG4115.
Restart This screen allows you to reboot the NBG4115 without
turning the power off.
Sys OP Mode General This screen allows you to select whether your device
acts as a Router or a Access Point.
Language Language This screen allows you to select the language you
prefer.
Table 4 Screens Summary
LINK TAB FUNCTION
