Chapter 16 Bandwidth Management
User’s Guide
159
The following table describes the labels in this screen.
16.3 Advanced
Use this screen to configure bandwidth managements rule for the pre-defined
services or applications.
Use this screen to configure bandwidth managements rule for specific protocols on
an IP or IP range.
Note: This screen contains the Priority Queue and Bandwidth Allocation tables.
Though both tables are described in this section, you can only apply the rules in
one table. Fill out the table of the Bandwidth Management Type you selected
in
Section 16.2 on page 158
Table 55 Management > Bandwidth MGMT > General
LABEL DESCRIPTION
Service Management
Bandwidth
Management
Type
This field allows you to have NBG4115 apply bandwidth management.
Select Priority Queue or Bandwidth Allocation to enable
bandwidth management.
Select Priority Queue to allocate bandwidth based on the pre-defined
priority assigned to an application. Refer to
Section 16.3 on page 159 .
Select Bandwidth Allocation allocate specific amounts of bandwidth
to specific protocols on an IP or IP range. Refer to
Section 16.3 on
page 159 .
Select Disable if you do not want to use this feature.
Total Bandwidth Setting. The fields below appear when you enable Bandwidth
Management.
Uplink
Select the total amount of bandwidth (from 64 Kilobits to 30 Megabits)
that you want to dedicate to uplink traffic.
This is traffic from LAN/WLAN to WAN.
Downlink Select the total amount of bandwidth (from 64 Kilobits to 30 Megabits)
that you want to dedicate to uplink traffic.
This is traffic from WAN to LAN/WLAN.
Apply Click Apply to save your customized settings.
Reset Click Reset to begin configuring this screen afresh.
