Chapter 8 WAN
User’s Guide
112
The following table describes the labels in this screen.
Table 39 Network > WAN > Internet Connection: Mobile 3G
LABEL DESCRIPTION
ISP Parameters for Internet Access
Connection Type
3G is .
To configure a Mobile 3G client, you must configure the User Name
and Password fields as well as PIN Code, APN Code, and Dial
Number.
Internet Service
Provider Select your ISP from this list, if it is pre-configured.
PIN Code Enter the 4-digit 3G account PIN code given to you by your ISP.
APN Code Enter the Access Point Name (APN) given to you by your ISP.
Dial Number Enter the phone number that must be dialed in order to login to
your 3G account from the NBG4115.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the User Name above.
Nailed-up
Connection Select Nailed-Up Connection if you do not want the connection to
time out.
Idle Timeout This value specifies the time in minutes that elapses before the
NBG4115 automatically disconnects from the PPTP server.
DNS Servers
First DNS Server
Second DNS Server
Select From ISP if your ISP dynamically assigns DNS server
information (and the NBG4115's WAN IP address). The field to the
right displays the (read-only) DNS server IP address that the ISP
assigns.
Select User-Defined if you have the IP address of a DNS server.
Enter the DNS server's IP address in the field to the right. If you
chose User-Defined, but leave the IP address set to 0.0.0.0, User-
Defined changes to None after you click Apply. If you set a second
choice to User-Defined, and enter the same IP address, the
second User-Defined changes to None after you click Apply.
Select None if you do not want to configure DNS servers. If you do
not configure a DNS server, you must know the IP address of a
computer in order to access it.
WAN MAC Address The MAC address section allows users to configure the WAN port's
MAC address by either using the NBG4115’s MAC address, copying
the MAC address from a computer on your LAN or manually entering
a MAC address.
Factory default Select Factory default to use the factory assigned default MAC
Address.
Clone the
computer’s MAC
address - IP
Address Select Clone the computer's MAC address - IP Address and
enter the IP address of the computer on the LAN whose MAC you
are cloning. Once it is successfully configured, the address will be
copied to the rom file. It will not change unless you change the
setting or upload a different ROM file.
Set WAN MAC
Address Select this option and enter the MAC address you want to use.
