Page 82
P-2302HW/HWL-P1 Series User’s Guide
82
Chapter 4 Status Screens
Figure 34 DHCP Table Window
Each field is described in the following table.
4.4 VoIP Statistics Window
This screen displays SIP registration information, status of calls and VoIP traffic statistics. To
access this screen, open the Status screen (see
), and click (Details ...)
next to VoIP Statistics.
Table 28 DHCP Table Window
LABEL
DESCRIPTION
#
This field is a sequential value. It is not associated with a specific entry.
IP Address
This field displays the IP address the ZyXEL Device assigned to a computer in the
network.
Host Name
This field displays the system name of the computer to which the ZyXEL Device
assigned the IP address.
MAC Address
This field displays the MAC address of the computer to which the ZyXEL Device
assigned the IP address.
Refresh
Click this to update this screen.
