P-2302HW/HWL-P1 Series User’s Guide
Chapter 14 Firewall
193
Figure 105 IP Alias
14.3 Firewall Screens
14.3.1 General Firewall Screen
Use this screen to configure the basic settings for your firewall. To access this screen, click
Security > Firewall > General.
Figure 106 Security > Firewall > General
Each field is described in the following table.
Table 79 Security > Firewall > General
LABEL
DESCRIPTION
Enable Firewall
Select this to activate the firewall. The ZyXEL Device controls access and protects
against Denial of Service (DoS) attacks when the firewall is activated.
Bypass Triangle
Route
Select this if you want to let some traffic from the WAN go directly to a computer in
the LAN without passing through the ZyXEL Device. See the appendices for more
information about triangle route topology.
