P-2302HW/HWL-P1 Series User’s Guide
206 Chapter 17 Bandwidth MGMT
17.1.2 Proportional Bandwidth Allocation
Bandwidth management allows you to define how much bandwidth each class gets; however,
the actual bandwidth allotted to each class decreases or increases in proportion to actual
available bandwidth.
17.1.3 Application-based Bandwidth Management
You can create bandwidth classes based on individual applications (like VoIP, Web, FTP, E-
mail and Video for example).
17.1.4 Subnet-based Bandwidth Management
You can create bandwidth classes based on subnets. The following figure shows LAN subnets.
You could configure one bandwidth class for subnet A and another for subnet B.
Figure 113 Subnet-based Bandwidth Management Example
17.1.5 Application- and Subnet-based Bandwidth Management
You could also create bandwidth classes based on a combination of a subnet and an
application. The following example table shows bandwidth allocations for application specific
traffic from separate LAN subnets.
Table 85 Application and Subnet-based Bandwidth Management Example
TRAFFIC TYPE FROM SUBNET A FROM SUBNET B
VoIP 64 Kbps 64 Kbps
Web 64 Kbps 64 Kbps
FTP 64 Kbps 64 Kbps
E-mail 64 Kbps 64 Kbps
Video 64 Kbps 64 Kbps
