Producing Sound
Playing a Sound with a MIDI Keyboard
You can play the SH-32’s sounds using a MIDI keyboard. To do so, you need to
connect the MIDI OUT connector of your keyboard with the MIDI IN connector of
the SH-32 (p. 16).
fig.003
1
Set the channel of the MIDI keyboard.
Set the MIDI transmit channel of the keyboard to Channel 1 (refer to the manual that
came with your MIDI keyboard).
2
Set the MIDI channel of the SH-32.
Set the MIDI receive channel to Channel 1.
1. Turn the FX/SYSTEM knob to “SYSTEM.”
2. Press [6 (MIDI CH)].
[6 (MIDI CH)] blinks, and the MIDI channel number appears in the display.
3. Press [VALUE ▼ / ▲ ] to select MIDI channel number “1.”
The MIDI receive channel on the SH-32 is set to channel 1.
4. Press [EXIT].
3
Play something on the MIDI keyboard.
The SH-32 sounds the notes that have been played on the MIDI keyboard.
See “Chapter 8. Using the
SH-32 with External MIDI
Devices” (p. 84) for details on
MIDI settings.
