117

Specifications

SH-32: Synthesizer

Parts

4 parts

Maximum Polyphony

32 voices

Sound Generator Organization

2 Oscillators + 1 Filter + 1 Amp + 2 LFOs

Suboscillator (with subsonic mode; can be switched on and off
independently of the oscillators), PWM function (can be switched on
and off independently of the oscillators), Oscillator Sync function,
Ring Modulator function (only one of the above functions may be
selected at any one time; Patches in Oscillator Sync are played in
mono)

LFO: 7 Waveforms, Tap Teach enabled in BPM Sync

Synth Oscillator Waveforms

7 groups, 67 types (SAW: 12, SQUARE: 10, PULSE: 9, PWM: 1,
TRIANGLE/SINE: 5, SPECTRUM: 20, NOISE: 10)

Waveforms for Use in Rhythm Sets

63 Waveforms (Pre-installed waveforms include TR-909 and TR-808
kick, snare, hi-hat, and other waves)

Effects

Insertion Effects: 35

Reverb/Delay: 10

Preset Memory

Patches: 128

Rhythm Sets: 2

User Memory

Patches: 128

Rhythm Sets: 2

Performances: 64

* The Patches in User memory are identical to those in the Preset

memory.

Arpeggiator

Arpeggio Styles: 64

Rhythm Styles: 64

Tempo: 20–250 BPM

Programmable (Realtime, Step)

Parameters: Grid Type, Duration, Octave Range, Motif

* Styles can be overwritten by the user.

Chord Memory

Chord Forms: 64

Display

8 segments x 3 characters LED

Connectors

MIDI Connectors (IN, OUT)

Output Jacks (L, R) (1/4 inch phone type)

Headphones Jack

Foot Switch Jack

DC In Jack

Power Supply

AC Adaptor (DC 9 V)

Current Draw

1000 mA

Dimensions

303 (W) x 228 (D) x 91.5 (H) mm

11-15/16 (W) x 9 (D) x 3-5/8 (H) inches

Weight

1.9 kg / 4 lbs 4 oz (excluding AC Adaptor)

Accessories

Owner’s Manual

AC Adaptor (ACI series or PSB-1U)

Options

Foot Switch: BOSS FS-5U

Pedal Switch: DP-2

Foot Switch Cable: PCS-31

In the interest of product improvement, the specifications and/
or appearance of this unit are subject to change without prior
notice.
