14
Panel Descriptions
[RANGE]/[MOTIF]
RANGE:
Press this button, causing the indicator to light, to set, in
octave units, the range in which arpeggios are played.
→
MOTIF:
Press this button, causing the indicator to blink, to select the
arpeggio variation to be played during arpeggio performances.
→
[GRID]/[DURATION]
GRID:
Press this button, causing the indicator to light, to select the
timing used to sound arpeggios during arpeggio performances.
→
DURATION:
Press this button, causing the indicator to blink, to
select the note length used to play arpeggios during arpeggio
performances.
→
[STYLE]/[STORE]
STYLE:
Press this button, causing the indicator to light, to select the
basic style used to play arpeggios.
→
STORE:
Press this button, causing the indicator to blink, to save the
arpeggio styles you have created.
→
[ON]
Switches the arpeggiator on/off.
→
Hold down [ON] and press [▼ (REALTIME)] to input arpeggio
styles in real time.
→
Hold down [ON] and press [▲ (STEP)] to input arpeggio styles in
steps.
→
[1]–[4/R]/[TIE], [REST], [TO TOP], [BACK]
1–4/R:
Selects the Parts that are to be played simultaneously in
Performance mode, or the Part for which settings are to be changed.
→
When you are inputting arpeggio styles in steps, these buttons
perform the following functions.
→
TIE:
Inputs a tie.
REST:
Inputs a rest.
TO TOP:
Returns you to the beginning grid line.
BACK:
Deletes the last note or rest that has been input.
[1/A]–[8/R]
These switch the tone banks and numbers.
→
Setting the FX/SYSTEM knob to “SYSTEM” allows for selection of
parameters with settings that affect the SH-32 as a whole (system
parameters).
→
[TAP (BPM)]
Sets the tempo (BPM) for arpeggios. You can also set the tempo by
tapping this button at the desired rhythm.
→
About the Symbols on the Panel
The following symbols, which appear on the SH-32’s panel, are
meant to depict the illumination state of the indicators.
: Lit
: Blinking
: Off
