115

Appendices

MIDI Transmit/Receive Setting List

Exc:

Exclusive Message

CC:

Control Change

* When Edit TxRx is set to “OFF,” the related Control Changes are not transmitted or received. Additionally, when set to “Mod1,” Control Changes

transmitted only in “Mod2” are not received.

* Parameters other than those mentioned in this list are transmitted as Exclusive messages.

Section

Parameter

“Mod1” (Mode 1)

“Mod2” (Mode 2)

Remarks

Patch Common/
Control

Level

CC07

CC07

CC07: Volume, Value: 0–127

Pan

CC10

CC10

CC10: Panpot, Value: 0–127 (64=Center)

Solo Switch

CC126/127

CC126/127

CC126: Mono (Solo)/CC127: Poly

Unison Switch

CC70

CC70

CC70: Sound Controller 1, Value: 0=OFF/1=ON

Portamento Time

CC05

CC05

CC05: Portamento Time, Value: 0–127

Portamento Type

Exc (Transmit/Receive)/
CC65 (Receive)

Exc (Transmit/Receive)/
CC65 (Receive)

CC65: Portamento, Value: 0–63=OFF/64–127=Fulltime,
Exc (OFF/Legato Only/Fulltime)

Legato Switch

Exc (Transmit/Receive)/
CC68 (Receive)

Exc (Transmit/Receive)/
CC68 (Receive)

CC68: Legato, Value: 0–63=OFF/64–127=ON,
Exc (OFF/ON/Retrigger)

OSC 1&2

Oscillator 1:2 Balance

CC08

CC08

CC08: Balance, Value: 1–127 (64=Center)

Pitch Env Attack Time

Exc

CC26

Value: 0–127

Pitch Env Decay Time

Exc

CC27

Value: 0–127

OSC 1

Pitch Env Depth

Exc

CC25

Value: 1–127 (64=Center)

PWM Depth

CC78

CC78

CC78: Sound Controller 9, Value: 0–127

Coarse Tune

Exc

CC21

Value: 40–88 (64=Center)

Fine Tune

CC77

CC77

CC77: Sound Controller 8, Value: 14–114 (64=Center)

OSC 2

Pitch Env Depth

Exc

CC57

Value: 1–127 (64=Center)

PWM Depth

CC79

CC79

CC79: Sound Controller 10, Value: 0–127

Coarse Tune

Exc

CC53

Value: 40–88 (64=Center)

Fine Tune

CC76

CC76

CC76: Sound Controller 7, Value: 14–114 (64=Center)

Filter

Filter Type

Exc

CC34

Value: 0–4

Cutoff Frequency

CC74

CC74

CC74: Sound Controller 5, Value: 0–127

Resonance

CC71

CC71

CC71: Sound Controller 2, Value: 0–127

Cutoff Kay Follow

Exc

CC30

Value: 44–84 (64=Center)

Env Depth

CC81

CC81

CC81: General Purpose Controller 6, Value: 1–127 (64=Center)

Env Attack Time

CC82

CC82

CC82: General Purpose Controller 7, Value: 0–127

Env Decay Time

CC83

CC83

CC83: General Purpose Controller 8, Value: 0–127

Env Sustain Time

Exc

CC28

Value: 0–127

Env Release Time

Exc

CC29

Value: 0–127

Amp

Env Attack Time

CC73

CC73

CC73: Sound Controller 4, Value: 0–127

Env Decay Time

CC75

CC75

CC75: Sound Controller 6, Value: 0–127

Env Sustain Time

Exc

CC31

Value: 0–127

Env Release Time

CC72

CC72

CC72: Sound Controller 3, Value: 0–127

LFO 1

Wave Form

Exc

CC15

Value: 0–6

Rate

CC16

CC16

CC16: General Purpose Controller 1, Value: 0–127

Fade Time

Exc

CC20

Value: 0–127

Oscillator 1 Depth

CC18

CC18

CC18: General Purpose Controller 3, Value: 1–127 (64=Center)

Oscillator 2 Depth

Exc

CC50

Value: 1–127 (64=Center)

Filter Depth

CC19

CC19

CC19: General Purpose Controller 4, Value: 1–127 (64=Center)

Amp Depth

CC80

CC80

CC80: General Purpose Controller 5, Value: 1–127 (64=Center)

Pan Depth

Exc

CC09

Value: 1–127 (64=Center)

LFO 2

Wave Form

Exc

CC47

Value: 0–6

Rate

CC17

CC17

CC17: General Purpose Controller 2, Value: 0–127

Fade Time

Exc

CC52

Value: 0–127

Oscillator 1 Depth

Exc

CC22

Value: 1–127 (64=Center)

Oscillator 2 Depth

Exc

CC54

Value: 1–127 (64=Center)

Filter Depth

Exc

CC23

Value: 1–127 (64=Center)

Amp Depth

Exc

CC24

Value: 1–127 (64=Center)

Pan Depth

Exc

CC41

Value: 1–127 (64=Center)

Patch Effect INS/
FX

Intensity

CC93

CC93

CC93: General Purpose Effect 3, Value: 0–127

Patch Effect REV/
DELAY

E.LEVEL

CC94

CC94

CC94: General Purpose Effect 4, Value: 0–127

FBK (Feedback)

CC13

CC13

CC13: Effect Control 2, Value: 0–98

Performance
Common/Control

Performance Level

CC07

CC07

CC07: Volume, Value: 0–127

Performance Part

Part Level

CC07

CC07

CC07: Volume, Value: 0–127

Part Pan

CC10

CC10

CC10: Panpot, Value: 1–127 (64=Center)

Performance Part
Effects

Part REV/DELAY
Send Level

CC91

CC91

CC91: General Purpose Effect 1, Value: 0–127

* All Exclusive messages are received in both “Mod1” and “Mod2.”
* When a parameter is contained in an Exclusive message in “Mod1,” it does not function if a CC corresponding to the same parameter is received.
