R61509V Target Spec
Rev. 0.11 April 25, 2008, page 80 of 181
7’h38 VREG1OUT x 0.716 7’h78 VREG1OUT x 0.972
7’h39 VREG1OUT x 0.720 7’h79 VREG1OUT x 0.976
7’h3A VREG1OUT x 0.724 7’h7A VREG1OUT x 0.980
7’h3B VREG1OUT x 0.728 7’h7B VREG1OUT x 0.984
7’h3C VREG1OUT x 0.732 7’h7C VREG1OUT x 0.988
7’h3D VREG1OUT x 0.736 7’h7D VREG1OUT x 0.992
7’h3E VREG1OUT x 0.740 7’h7E VREG1OUT x 0.996
7’h3F VREG1OUT x 0.744 7’h7F VREG1OUT x 1.000
Notes: 1. Make sure the VCOMH level is between 3.0V to (DDVDH-0.5)V.
2. The above setting is enabled when internal electronic volume is selected for setting the VCOMH
level.
