Renesas R61509V User Manual
Page 33
R61509V Pad Coordinate （Unit：
μm）
2008.04.21 rev0.1
pad No
pad name
X
Y
pad No
pad name
X
Y
1201 S12
-5707.5
276.0
1251 G359
-6652.5
157.0
1202 S11
-5722.5
157.0
1252 G357
-6667.5
276.0
1203 S10
-5737.5
276.0
1253 G355
-6682.5
157.0
1204 S9
-5752.5
157.0
1254 G353
-6697.5
276.0
1205 S8
-5767.5
276.0
1255 G351
-6712.5
157.0
1206 S7
-5782.5
157.0
1256 G349
-6727.5
276.0
1207 S6
-5797.5
276.0
1257 G347
-6742.5
157.0
1208 S5
-5812.5
157.0
1258 G345
-6757.5
276.0
1209 S4
-5827.5
276.0
1259 G343
-6772.5
157.0
1210 S3
-5842.5
157.0
1260 G341
-6787.5
276.0
1211 S2
-5857.5
276.0
1261 G339
-6802.5
157.0
1212 S1
-5872.5
157.0
1262 G337
-6817.5
276.0
1213 TESTO14
-5887.5
276.0
1263 G335
-6832.5
157.0
1214 VGLDMY3
-6097.5
276.0
1264 G333
-6847.5
276.0
1215 G431
-6112.5
157.0
1265 G331
-6862.5
157.0
1216 G429
-6127.5
276.0
1266 G329
-6877.5
276.0
1217 G427
-6142.5
157.0
1267 G327
-6892.5
157.0
1218 G425
-6157.5
276.0
1268 G325
-6907.5
276.0
1219 G423
-6172.5
157.0
1269 G323
-6922.5
157.0
1220 G421
-6187.5
276.0
1270 G321
-6937.5
276.0
1221 G419
-6202.5
157.0
1271 G319
-6952.5
157.0
1222 G417
-6217.5
276.0
1272 G317
-6967.5
276.0
1223 G415
-6232.5
157.0
1273 G315
-6982.5
157.0
1224 G413
-6247.5
276.0
1274 G313
-6997.5
276.0
1225 G411
-6262.5
157.0
1275 G311
-7012.5
157.0
1226 G409
-6277.5
276.0
1276 G309
-7027.5
276.0
1227 G407
-6292.5
157.0
1277 G307
-7042.5
157.0
1228 G405
-6307.5
276.0
1278 G305
-7057.5
276.0
1229 G403
-6322.5
157.0
1279 G303
-7072.5
157.0
1230 G401
-6337.5
276.0
1280 G301
-7087.5
276.0
1231 G399
-6352.5
157.0
1281 G299
-7102.5
157.0
1232 G397
-6367.5
276.0
1282 G297
-7117.5
276.0
1233 G395
-6382.5
157.0
1283 G295
-7132.5
157.0
1234 G393
-6397.5
276.0
1284 G293
-7147.5
276.0
1235 G391
-6412.5
157.0
1285 G291
-7162.5
157.0
1236 G389
-6427.5
276.0
1286 G289
-7177.5
276.0
1237 G387
-6442.5
157.0
1287 G287
-7192.5
157.0
1238 G385
-6457.5
276.0
1288 G285
-7207.5
276.0
1239 G383
-6472.5
157.0
1289 G283
-7222.5
157.0
1240 G381
-6487.5
276.0
1290 G281
-7237.5
276.0
1241 G379
-6502.5
157.0
1291 G279
-7252.5
157.0
1242 G377
-6517.5
276.0
1292 G277
-7267.5
276.0
1243 G375
-6532.5
157.0
1293 G275
-7282.5
157.0
1244 G373
-6547.5
276.0
1294 G273
-7297.5
276.0
1245 G371
-6562.5
157.0
1295 G271
-7312.5
157.0
1246 G369
-6577.5
276.0
1296 G269
-7327.5
276.0
1247 G367
-6592.5
157.0
1297 G267
-7342.5
157.0
1248 G365
-6607.5
276.0
1298 G265
-7357.5
276.0
1249 G363
-6622.5
157.0
1299 G263
-7372.5
157.0
1250 G361
-6637.5
276.0
1300 G261
-7387.5
276.0
