Specifications of Power-supply Circuit External Elements
The specifications of external elements connected to the power-supply circuit of the R61509V are as
follows.
Table 77 Capacitor
Capacitance
Voltage proof
Pin Connection
6 V
(1) VREG1OUT, (3) VCI1, (4) C11P, C11M, (5) C12P, C12M,
(7) C13P, C13M, (14) VCL, (16) VCOMH, (17) VCOML
10 V
(6) DDVDH, (8) C21P, C21M, (9) C22P, C22M
1µF
(B characteristics)
25 V
(10) VGH, (12) VGL
Table 78 Schottky Diode
Specification
Pin Connection
VF < 0.38 V/20 mA@25
°C, VR ≥ 25 V
(Recommended diode: HS*226)
(13) GND–VGL,
(11) DDVDH–VGH,
Table 79 Variable Resistor
Specification
Pin Connection
> 200 k
Ω
(2) VCOMR
Table 80 Internal Logic Power Supply
Capacitance
Voltage proof (recommended)
Pin Connection
1µF (B characteristics)
3V
(15) VDD
