R61509V Target Spec
Rev. 0.11 April 25, 2008, page 39 of 181
Table 12 GRAM address and display position on the panel (SS = 1, BGR = 1)
S/G pin
S720 S719 S718 S717 S716 S715 S714 S713 S712 S711 S710 S709
・・・・・
S12 S11 S10 S9 S8 S7 S6 S5 S4 S3 S2 S1
GS=0 GS=1 WD[17:0] WD[17:0] WD[17:0] WD[17:0] ・・・・・ WD[17:0] WD[17:0] WD[17:0] WD[17:0]
G1 G432 h00000 h00001 h00002 h00003 ・・・・・ h000EC h000ED h000EE h000EF
G2 G431 h00100 h00101 h00102 h00103 ・・・・・ h001EC h001ED h001EE h001EF
G3 G430 h00200 h00201 h00202 h00203 ・・・・・ h002EC h002ED h002EE h002EF
G4 G429 h00300 h00301 h00302 h00303 ・・・・・ h003EC h003ED h003EE h003EF
G5 G428 h00400 h00401 h00402 h00403 ・・・・・ h004EC h004ED h004EE h004EF
G6 G427 h00500 h00501 h00502 h00503 ・・・・・ h005EC h005ED h005EE h005EF
G7 G426 h00600 h00601 h00602 h00603 ・・・・・ h006EC h006ED h006EE h006EF
G8 G425 h00700 h00701 h00702 h00703 ・・・・・ h007EC h007ED h007EE h007EF
G9 G424 h00800 h00801 h00802 h00803 ・・・・・ h008EC h008ED h008EE h008EF
G10 G423 h00900 h00901 h00902 h00903 ・・・・・ h009EC h009ED h009EE h009EF
G11 G422 h00A00 h00A01 h00A02 h00A03 ・・・・・ h00AEC h00AED h00AEE h00AEF
G12 G421 h00B00 h00B01 h00B02 h00B03 ・・・・・ h00BEC h00BED h00BEE h00BEF
G13 G420 h00C00 h00C01 h00C02 h00C03 ・・・・・ h00CEC h00CED h00CEE h00CEF
G14 G419 h00D00 h00D01 h00D02 h00D03 ・・・・・ h00DEC h00DED h00DEE h00DEF
G15 G418 h00E00 h00E01 h00E02 h00E03 ・・・・・ h00EEC h00EED h00EEE h00EEF
G16 G417 h00F00 h00F01 h00F02 h00F03 ・・・・・ h00FEC h00FED h00FEE h00FEF
G17 G416 h01000 h01001 h01002 h01003 ・・・・・ h010EC h010ED h010EE h010EF
G18 G415 h01100 h01101 h01102 h01103 ・・・・・ h011EC h011ED h011EE h011EF
G19 G414 h01200 h01201 h01202 h01203 ・・・・・ h012EC h012ED h012EE h012EF
G20 G413 h01300 h01301 h01302 h01303 ・・・・・ h013EC h013ED h013EE h013EF
： ： ： ： ： ： ： ： ： ：
： ： ： ： ： ： ： ： ： ：
G417 G16 h1A000 h1A001 h1A002 h1A003 ・・・・・ h1A0EC h1A0ED h1A0EE h1A0EF
G418 G15 h1A100 h1A101 h1A102 h1A103 ・・・・・ h1A1EC h1A1ED h1A1EE h1A1EF
G419 G14 h1A200 h1A201 h1A202 h1A203 ・・・・・ h1A2EC h1A2ED h1A2EE h1A2EF
G420 G13 h1A300 h1A301 h1A302 h1A303 ・・・・・ h1A3EC h1A3ED h1A3EE h1A3EF
G421 G12 h1A400 h1A401 h1A402 h1A403 ・・・・・ h1A4EC h1A4ED h1A4EE h1A4EF
G422 G11 h1A500 h1A501 h1A502 h1A503 ・・・・・ h1A5EC h1A5ED h1A5EE h1A5EF
G423 G10 h1A600 h1A601 h1A602 h1A603 ・・・・・ h1A6EC h1A6ED h1A6EE h1A6EF
G424 G9 h1A700 h1A701 h1A702 h1A703 ・・・・・ h1A7EC h1A7ED h1A7EE h1A7EF
G425 G8 h1A800 h1A801 h1A802 h1A803 ・・・・・ h1A8EC h1A8ED h1A8EE h1A8EF
G426 G7 h1A900 h1A901 h1A902 h1A903 ・・・・・ h1A9EC h1A9ED h1A9EE h1A9EF
G427 G6 h1AA00 h1AA01 h1AA02 h1AA03 ・・・・・ h1AAEC h1AAED h1AAEE h1AAEF
G428 G5 h1AB00 h1AB01 h1AB02 h1AB03 ・・・・・ h1ABEC h1ABED h1ABEE h1ABEF
G429 G4 h1AC00 h1AC01 h1AC02 h1AC03 ・・・・・ h1ACEC h1ACED h1ACEE h1ACEF
G430 G3 h1AD00 h1AD01 h1AD02 h1AD03 ・・・・・ h1ADEC h1ADED h1ADEE h1ADEF
G431 G2 h1AE00 h1AE01 h1AE02 h1AE03 ・・・・・ h1AEEC h1AEED h1AEEE h1AEEF
G432 G1 h1AF00 h1AF01 h1AF02 h1AF03 ・・・・・ h1AFEC h1AFED h1AFEE h1AFEF
