R61509V Target Spec
Rev. 0.11 April 25, 2008, page 145 of 181
Interpolation Registers
Table 72 Interpolation Registers
Gamma Control
Interpolation
adjustment Positive
polarity
Negative
polarity
PI0P0[1:0] PI0N0[1:0]
V2~V7
PI0P1[1:0] PI0N1[1:0]
PI0P2[1:0] PI0N2[1:0]
V56~V61
PI0P3[1:0] PI0N3[1:0]
Table 73 Interpolation factor for V2 to V7
(See “Grayscale Voltage Calculation Formula” for IPV* level)
PI0*0[1:0] PI0*1[1:0] IPV2 IPV3 IPV4 IPV5 IPV6 IPV7
2'h0 81% 67% 52% 39% 26% 13%
2'h1 78% 61% 43% 33% 22% 11%
2'h2 73% 52% 31% 23% 15% 8%
2'h0
2'h3 72% 50% 28% 21% 14% 7%
2'h0 80% 68% 56% 42% 28% 14%
2'h1 76% 62% 48% 36% 24% 12%
2'h2 70% 52% 35% 26% 17% 9%
2'h1
2'h3 69% 50% 31% 23% 16% 8%
2'h0 78% 70% 61% 46% 30% 15%
2'h1 74% 63% 53% 39% 26% 13%
2'h2 66% 53% 39% 29% 20% 10%
2'h2
2'h3 64% 50% 36% 27% 18% 9%
2'h0 78% 70% 63% 47% 31% 16%
2'h1 73% 64% 54% 41% 27% 14%
2'h2 65% 53% 41% 31% 20% 10%
2'h3
2'h3 63% 50% 37% 28% 19% 9%
