Table 60
Table 61
FMP[8:0] FMARK
output
position
9’h000 0
9’h001 1
st
line
9’h002 2
nd
line
:
9’h1BD 445
th
line
9’h1BE 446
th
line
9’h1BF 447
th
line
9’h1C0 ~ 1FF
Setting disabled
FMI[2] FMI[1] FMI[0]
FMARK
Output
interval
0 0 0
One frame period
0 0 1
2 frame periods
0 1 1
4 frame periods
1 0 1
6 frame periods
Other setting
Setting disabled
