R61509V Pad Coordinate （Unit： μm） 2008.04.21 rev0.1
pad No pad name X Y pad No pad name X Y
101 GNDDUM8 -2135.0 -269.0 151 GND 1365.0 -269.0
102 DB3 -2065.0 -269.0 152 GND 1435.0 -269.0
103 DB2 -1995.0 -269.0 153 GND 1505.0 -269.0
104 DB1 -1925.0 -269.0 154 VGS 1575.0 -269.0
105 DB0 -1855.0 -269.0 155 AGND 1645.0 -269.0
106 GNDDUM9 -1785.0 -269.0 156 AGND 1715.0 -269.0
107 CSX -1715.0 -269.0 157 AGND 1785.0 -269.0
108 RS -1645.0 -269.0 158 AGND 1855.0 -269.0
109 WRX_SCL -1575.0 -269.0 159 AGND 1925.0 -269.0
110 RDX -1505.0 -269.0 160 AGND 1995.0 -269.0
111 GNDDUM10 -1435.0 -269.0 161 AGND 2065.0 -269.0
112 FMARK -1365.0 -269.0 162 AGND 2135.0 -269.0
113 SDI -1295.0 -269.0 163 AGND 2205.0 -269.0
114 SDO -1225.0 -269.0 164 VTEST 2275.0 -269.0
115 VDD -1155.0 -269.0 165 VCIR 2345.0 -269.0
116 VDD -1085.0 -269.0 166 VREG1OUT 2415.0 -269.0
117 VDD -1015.0 -269.0 167 VCOMR 2485.0 -269.0
118 VDD -945.0 -269.0 168 C11M 2555.0 -269.0
119 VDD -875.0 -269.0 169 C11M 2625.0 -269.0
120 VDD -805.0 -269.0 170 C11M 2695.0 -269.0
121 VDD -735.0 -269.0 171 C11M 2765.0 -269.0
122 VDD -665.0 -269.0 172 C11M 2835.0 -269.0
123 VDD -595.0 -269.0 173 C11P 2905.0 -269.0
124 VMON -525.0 -269.0 174 C11P 2975.0 -269.0
125 VCOM -455.0 -269.0 175 C11P 3045.0 -269.0
126 VCOM -385.0 -269.0 176 C11P 3115.0 -269.0
127 VCOM -315.0 -269.0 177 C11P 3185.0 -269.0
128 VCOM -245.0 -269.0 178 C12M 3255.0 -269.0
129 VCOM -175.0 -269.0 179 C12M 3325.0 -269.0
130 VCOM -105.0 -269.0 180 C12M 3395.0 -269.0
131 VCOM -35.0 -269.0 181 C12M 3465.0 -269.0
132 VCOM 35.0 -269.0 182 C12M 3535.0 -269.0
133 VCOMH 105.0 -269.0 183 C12P 3605.0 -269.0
134 VCOMH 175.0 -269.0 184 C12P 3675.0 -269.0
135 VCOMH 245.0 -269.0 185 C12P 3745.0 -269.0
136 VCOMH 315.0 -269.0 186 C12P 3815.0 -269.0
137 VCOMH 385.0 -269.0 187 C12P 3885.0 -269.0
138 VCOMH 455.0 -269.0 188 DDVDH 3955.0 -269.0
139 VCOML 525.0 -269.0 189 DDVDH 4025.0 -269.0
140 VCOML 595.0 -269.0 190 DDVDH 4095.0 -269.0
141 VCOML 665.0 -269.0 191 DDVDH 4165.0 -269.0
142 VCOML 735.0 -269.0 192 DDVDH 4235.0 -269.0
143 VCOML 805.0 -269.0 193 DDVDH 4305.0 -269.0
144 VCOML 875.0 -269.0 194 DDVDH 4375.0 -269.0
145 GND 945.0 -269.0 195 DDVDH 4445.0 -269.0
146 GND 1015.0 -269.0 196 DDVDH 4515.0 -269.0
147 GND 1085.0 -269.0 197 VCI1 4585.0 -269.0
148 GND 1155.0 -269.0 198 VCI1 4655.0 -269.0
149 GND 1225.0 -269.0 199 VCI1 4725.0 -269.0
150 GND 1295.0 -269.0 200 VCI1 4795.0 -269.0
