R61509V Target Spec
Rev. 0.11 April 25, 2008, page 52 of 181
External Display Interface Control 2 (R00Fh)
R/W RS IB15 IB14 IB13 IB12 IB11 IB10 IB9 IB8 IB7 IB6 IB5 IB4 IB3 IB2 IB1 IB0
R/W 1 0 0 0 0 0 0 0 0 0 0 0 VSPL HSPL 0 EPL DPL
Default value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DPL: Sets the signal polarity of DOTCLK pin.
DPL = 0: input data on the rising edge of DOTCLK
DPL = 1: input data on the falling edge of DOTCLK
EPL: Sets the signal polarity of ENABLE pin.
EPL = 0: writes data DB17-0 when ENABLE = “0” and disables data write operation
when ENABLE = “1”.
EPL = 1: writes data DB17-0 when ENABLE = “1” and disables data write operation
when ENABLE = “0”.
HSPL: Sets the signal polarity of HSYNCX pin.
HSPL = 0: low active
HSPL = 1: high active
VSPL: Sets the signal polarity of VSYNCX pin.
VSPL = 0: low active
VSPL = 1: high active
