Clock Synchronous Serial Interface Timing Characteristics
(IOVCC=1.65V~3.30V) TBD
Table 90
Item Symbol Unit Test condition Min. Typ. Max.
Write (receive) t SCYC ns Figure B 100
(TBD) － 20,000 Serial clock cycle
time
Read (transmit) t SCYC ns Figure B 350
(TBD)
－ 20,000
Write (receive) t SCH ns Figure B 40
(TBD)
－ － Serial clock
high-level width
Read (transmit) t SCH ns Figure B 150
(TBD)
－ －
Write (receive) t SCL ns Figure B 40
(TBD) － － Serial clock
low-level width
Read (transmit) t SCL ns Figure B 150
(TBD)
－ －
Serial clock rise/fall time t SCr， t SCf ns Figure B － － 15
(TBD)
Chip select setup time t CSU ns Figure B 20
(TBD) － －
Chip select hold time t CH ns Figure B 60
(TBD)
－ －
Serial input data setup time t SISU ns Figure B 30
(TBD)
－ －
Serial input data hold time t SIH ns Figure B 30
(TBD) － －
Serial output data delay time t SOD ns Figure B － － 130
(TBD)
Serial output data delay time t SOH ns Figure B 5
(TBD)
－ －
RGB Interface Timing Characteristics
(18-/16-bit RGB interface, IOVCC=1.65V~3.30V) TBD
Table 91
Item Symbol Unit Test condition Min. Typ. Max.
VSYNC/HSYNC setup time tSYNCS clock Figure D 0.5
(TBD)
－ 1.5
ENABLE setup time tENS ns Figure D 10
(TBD)
－ －
ENABLE hold time tENH ns Figure D 20
(TBD) － －
DOTCLK low-level pulse width PW DL ns Figure D 40
(TBD)
－ －
DOTCLK high-level pulse width PW DH ns Figure D 40
(TBD)
－ －
DOTCLK cycle time tCYCD ns Figure D 100
(TBD) － －
Data setup time tPDS ns Figure D 10
(TBD)
－ －
Data hold time tPDH ns Figure D 40
(TBD)
－ －
DOTCLK, VSYNCX and HSYNCX
rise/fall time trgbr，
trgbf
ns Figure D － － 15
