R61509V Target Spec
Rev. 0.11 April 25, 2008, page 79 of 181
Table 48
VCM [6:0] VCOMH voltage VCM [6:0] VCOMH voltage
7’h00 VREG1OUT x 0.492 7’h40 VREG1OUT x 0.748
7’h01 VREG1OUT x 0.496 7’h41 VREG1OUT x 0.752
7’h02 VREG1OUT x 0.500 7’h42 VREG1OUT x 0.756
7’h03 VREG1OUT x 0.504 7’h43 VREG1OUT x 0.760
7’h04 VREG1OUT x 0.508 7’h44 VREG1OUT x 0.764
7’h05 VREG1OUT x 0.512 7’h45 VREG1OUT x 0.768
7’h06 VREG1OUT x 0.516 7’h46 VREG1OUT x 0.772
7’h07 VREG1OUT x 0.520 7’h47 VREG1OUT x 0.776
7’h08 VREG1OUT x 0.524 7’h48 VREG1OUT x 0.780
7’h09 VREG1OUT x 0.528 7’h49 VREG1OUT x 0.784
7’h0A VREG1OUT x 0.532 7’h4A VREG1OUT x 0.788
7’h0B VREG1OUT x 0.536 7’h4B VREG1OUT x 0.792
7’h0C VREG1OUT x 0.540 7’h4C VREG1OUT x 0.796
7’h0D VREG1OUT x 0.544 7’h4D VREG1OUT x 0.800
7’h0E VREG1OUT x 0.548 7’h4E VREG1OUT x 0.804
7’h0F VREG1OUT x 0.552 7’h4F VREG1OUT x 0.808
7’h10 VREG1OUT x 0.556 7’h50 VREG1OUT x 0.812
7’h11 VREG1OUT x 0.560 7’h51 VREG1OUT x 0.816
7’h12 VREG1OUT x 0.564 7’h52 VREG1OUT x 0.820
7’h13 VREG1OUT x 0.568 7’h53 VREG1OUT x 0.824
7’h14 VREG1OUT x 0.572 7’h54 VREG1OUT x 0.828
7’h15 VREG1OUT x 0.576 7’h55 VREG1OUT x 0.832
7’h16 VREG1OUT x 0.580 7’h56 VREG1OUT x 0.836
7’h17 VREG1OUT x 0.584 7’h57 VREG1OUT x 0.840
7’h18 VREG1OUT x 0.588 7’h58 VREG1OUT x 0.844
7’h19 VREG1OUT x 0.592 7’h59 VREG1OUT x 0.848
7’h1A VREG1OUT x 0.596 7’h5A VREG1OUT x 0.852
7’h1B VREG1OUT x 0.600 7’h5B VREG1OUT x 0.856
7’h1C VREG1OUT x 0.604 7’h5C VREG1OUT x 0.860
7’h1D VREG1OUT x 0.608 7’h5D VREG1OUT x 0.864
7’h1E VREG1OUT x 0.612 7’h5E VREG1OUT x 0.868
7’h1F VREG1OUT x 0.616 7’h5F VREG1OUT x 0.872
7’h20 VREG1OUT x 0.620 7’h60 VREG1OUT x 0.876
7’h21 VREG1OUT x 0.624 7’h61 VREG1OUT x 0.880
7’h22 VREG1OUT x 0.628 7’h62 VREG1OUT x 0.884
7’h23 VREG1OUT x 0.632 7’h63 VREG1OUT x 0.888
7’h24 VREG1OUT x 0.636 7’h64 VREG1OUT x 0.892
7’h25 VREG1OUT x 0.640 7’h65 VREG1OUT x 0.896
7’h26 VREG1OUT x 0.644 7’h66 VREG1OUT x 0.900
7’h27 VREG1OUT x 0.648 7’h67 VREG1OUT x 0.904
7’h28 VREG1OUT x 0.652 7’h68 VREG1OUT x 0.908
7’h29 VREG1OUT x 0.656 7’h69 VREG1OUT x 0.912
7’h2A VREG1OUT x 0.660 7’h6A VREG1OUT x 0.916
7’h2B VREG1OUT x 0.664 7’h6B VREG1OUT x 0.920
7’h2C VREG1OUT x 0.668 7’h6C VREG1OUT x 0.924
7’h2D VREG1OUT x 0.672 7’h6D VREG1OUT x 0.928
7’h2E VREG1OUT x 0.676 7’h6E VREG1OUT x 0.932
7’h2F VREG1OUT x 0.680 7’h6F VREG1OUT x 0.936
7’h30 VREG1OUT x 0.684 7’h70 VREG1OUT x 0.940
7’h31 VREG1OUT x 0.688 7’h71 VREG1OUT x 0.944
7’h32 VREG1OUT x 0.692 7’h72 VREG1OUT x 0.948
7’h33 VREG1OUT x 0.696 7’h73 VREG1OUT x 0.952
7’h34 VREG1OUT x 0.700 7’h74 VREG1OUT x 0.956
7’h35 VREG1OUT x 0.704 7’h75 VREG1OUT x 0.960
7’h36 VREG1OUT x 0.708 7’h76 VREG1OUT x 0.964
7’h37 VREG1OUT x 0.712 7’h77 VREG1OUT x 0.968
