R61509V Target Spec
Rev. 0.11 April 25, 2008, page 49 of 181
8 Color Control (R00Bh)
R/W RS IB15 IB14 IB13 IB12 IB11 IB10 IB9 IB8 IB7 IB6 IB5 IB4 IB3 IB2 IB1 IB0
W/R 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 COL
Default value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
COL: When COL = 1, the R61509V enters the eight-color display mode. RAM data rewrite operation is
not required when setting the eight-color display mode. Set the 8-color mode instruction according to the
8-color mode sequence.
The electrical potential of liquid crystal drive in 8-color display mode is V0/V63. Selecting frame inversion
is recommended to reduce power consumption.
Table 17
COL Display Color
1’h0 262,144 colors
1’h 1 8 colors
