Replacing the pcu, Photoconductor unit (pcu) – Ricoh AFICIO MP01 User Manual
Page 64
MAINTAINING THE PRINTER
3-6
PHOTOCONDUCTOR UNIT (PCU)
The PCU should be replaced when print quality starts to deteriorate, or when the
“Change PCU” message appears on the Control Panel.
Replacing the PCU
Use the following procedure to replace the PCU.
1
Open the Front Cover.
2
Move the curved blue lever
“B1”down to the left.
3
Pressing down on the top of the
PCU as shown in the illustration,
pull it out of the machine.
