Ricoh AFICIO MP01 - Manual (Page 42)

USING THE CONTROL PANEL
2-10
Width/Length
You use this option to specify the dimensions of a custom paper size you want
to use in the By-pass Tray. The paper size settings are as follows:
❐ Width - specifies the length of the edge of the paper perpendicular to the
feeding direction, in millimeters.
❐ Length - specifies the length of the edge of the paper parallel to the feeding
direction, in millimeters.
Use the [
5
] key or the [
6
] key to select the dimension value. Holding either
key down increases or decreases the value in increments of ten. After you
select the value you want, press the [
] key to save your selection.
Note: For detailed information on printing custom size paper, refer to the Printer
Driver/Utility Reference and the Printer Driver/Utility
Reference
 -option>.
Envelope Size Selection
You use this option to specify the size of the envelopes loaded in the Envelope
Feeder. This menu option displays only when the optional Envelope Feeder is
installed. The options are as follows:
❐ 4 1 /
8
" x 9 1 /
2
"
L
❐ C5 Env
L
(COM 10 Env) ❐ C6 Env
L
❐ 3 7 /
8
" x 7 1 /
2
"
L
❐ DL Env
L
(Monarch Env)
The default value is 4 1 /
8
" x 9 1 /
2
"
L
(COM 10 Env).
