SPECIFICATIONS
6-9
SPECIFIC
A
TIONS
Parallel Interface
The parallel connection is a bi-directional parallel interface and requires a standard
36-pin parallel cable and a parallel port available on the host computer. Do not
use a parallel cable longer than three meters (ten feet).
Table6-7 lists the parallel pin designations and associated signals.
Table 6-7. Parallel pin designations
Code Signal Pin
STROBE Strobe 1
D<0> Data 2
D<1> Data 3
D<2> Data 4
D<3> Data 5
D<4> Data 6
D<5> Data 7
D<6> Data 8
D<7> Data 9
ACK* Acknowledge 10
BUSY Busy 11
PE Paper Error 12
SEL Select Out 13
AUTOFD* Auto Feed 14
(N/C) (Not Connected) 15
GND Ground 16
GND Ground 17
+5 VDC 5 Volts Direct Current 18
GND Ground 19
GND Ground 20
GND Ground 21
GND Ground 22
GND Ground 23
GND Ground 24
GND Ground 25
GND Ground 26
GND Ground 27
GND Ground 28
GND Ground 29
GND Ground 30
INIT* Initialization 31
FAULT* Fault 32
(N/C) (Not Connected) 33
(N/C) (Not Connected) 34
(N/C) (Not Connected) 35
SELIN Select In 36
