Page 26
SETTING UP
1-5
SETTING UP
CONNECTING TO THE HOST COMPUTER
Connect the machine to your host computer using a parallel cable compliant
with IEEE 1284 (supplied by you ).
Connecting the Parallel Cable
Follow these steps to connect the machine to your host computer:
1
Make sure you have the correct
cable.
2
Make sure both the machine and
your host computer are turned off.
3
Plug the 36-pin end of the parallel
cable into the parallel port on the
left side of the controller cover on
the back of the machine.
