M306NKT-EPB User’s Manual

4. Hardware Specifications

REJ10J0519-0200 Rev.2.00 Oct. 16, 2006

Page 87 of 104


4.5 External Dimensions


4.5.1 External Dimensions of the Emulation Probe
Figure 4.8 shows external dimensions of the M306NKT-EPB.

6NK

100.0

60.0

15.0

15.0

55.0

15.0

5.5

10.8

16.3

34.3

10.0

9.5

21.0

9.5

10.0

Unit: mm

Figure 4.8 External dimensions of the emulation probe
