M306NKT-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006 Page 59 of 104
(2) Setting address match breakpoints
1. Setting and executing address match breakpoint
Program execution with address match breakpoint
An address match breakpoint can be set by selecting “Enable the
Address Match Interrupt Break Function” in Init dialog box of the
MCU tab.
- A software breakpoint can be set or cleared by double-clicking the
address match breakpoint display area in the editor (source)
window (A blue circle is displayed at the setting line). Up to eight
points can be set.
- Click the execution button.
2. Execution completed with address match break
The cursor stops in the position where the address match break was
set up.
The statement in which the address match break was set up is not
executed.
