Page 58
M306NKT-EPB User’s Manual
3. Usage (How to Use the Emulator Debugger)
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006
Page 56 of 104
3.1.3 Checking Connections of the Emulator System
Checking connections of the emulator system
When the emulator debugger is connected correctly to the emulator after
you have finished setting up the Init dialog box and the MCU Setting
dialog box, you will see a message “Connected” displayed on the
“Debug” tab of the Output window.
