M306NKT-EPB User’s Manual 2. Setup
REJ10J0519-0200 Rev.2.00 Oct. 16, 2006 Page 32 of 104
Emulation probe
M30800T - PTC
(included)
M3T -F160 - 100NSD
100-pin LQFP
M3T-100LCC-QSD
100-pin LQFP
M3T - F 160-128 NRD
128-pin LQFP
100-pin
0.5mm pitch
● : No. 1 pin
128-pin
0.5mm pitch
(not included) (not included) (not included)
Figure 2.8 Connecting the user system according to user system (for M16C/6NK, M16C/6NL, M16C/6NM and M16C/6NN)
CAUTION
Note on Connecting the User System:
z Take care not to attach a converter board in a wrong direction. It may cause a fatal damage to the emulator and
user system.
